Specifications

• Specifications can be forwarded through to Council/engineers upon request.
• Four sizes of tank are available.

Tank capacity	Diameter	Height	Weight
5,000 litres	1930mm	2240mm*	2.97 tonne
9,090 litres	2440mm	2460mm	3.9 tonne
13,640 litres	2870mm	2440mm	5.3 tonne
22,730 litres	3450mm	2740mm	7.5 tonne
*Heights and weights shown are for tank only.

• The non-trafficable cover slabs (150mm thick) have been designed to be buried a maximum of 1000mm below ground level
• The trafficable cover slabs (250mm thick) have been designed to be buried a maximum of 1750mm below ground level
